ASTM A516 GR. 60 (NACE + HIC) plates- a brief description of it

Are you looking for the quality of plates that are manufactured with both NACE and HIC standards? If yes, then it is best to buy ASTM A516 GR. 60 (NACE + HIC) plates. But, before you buy it, it is important for you to know about NACE and HIC standards. National Association of corrosion engineers or NACE is a standard in which different industrial products are manufactured. Plates that are manufactured using NACE and HIC standards considered best. These plates are widely used in boilermakers and fabricators when there is a big risk of hydrogen induced cracking.

Well, it is important to note that this ASTM A516 GR.60 grade plate suit best for pressure equipment and vessels where the H2S corrosion is high and can create problems. There are several leading manufacturers available all over the world, manufacturing best quality of plates. These plates are known best for their features like durability, ductility, resistance to corrosion, pitting and cracking and tensile strength. Moreover, the raw material used for manufacturing these plates is well tested and inspected by quality experts and inspection agencies. Furthermore, these plates are even available in different grades such as ASTM A516 GR.60, 55, 70 and 80.

Standard Specification for Carbon Steel, Pressure Vessel Plates, for Moderate- and Lower-Temperature Service. They use to advance and modern technology to manufacture these plates. Talking about its quality these plates are manufactured in accordance with the international and national quality standard. The size of these plates varies as per customers demand and requirement whereas its normal size varies from 6mm to 105mm; its width varies from 2m, 2.5m and 3m whereas, the length of these plates ranges up to 12m. These plates are available in different shapes, sizes, and forms. The base of plates is hot dipped in zinc and coated with steel sheet or cold rolled with steel sheet. The manufacturers offer these plates in accordance with customer's requirement that is controlled rolled, annealing, normalizing, tempering or hot rolled forms.

There are several stages of manufacturing that is cutting, forming, machining, grinding and testing which is done under supervision and guidance of quality experts. These plates are widely used in industries and applications like engineer's machinery, boiler, and large structure steel, building construction and high-pressure containers. Before these plates are delivered to any industry they are tested and inspected. Few additional tests are done such as flattening test, Charpy V-Notch Impact Test, High-Temperature Tension Test, ultrasonic test and third-party inspection.

Certification and packaging
At the time of delivery, customers are offered with certifications like mill test certificate, radiography test certificate, IBR test certificate and third-party inspection and NACE and HIC test certificate. At last, when these ASTM A516 GR. 60 (NACE + HIC) plates are ready for the delivery they are packed in pallets, wooden cases or as per customers requirement. Furthermore, outside the packaging, the complete description of plates is given including size, length, thickness, and specification. These are the best quality of plates that are known for their strength, hardness, durability, and resistance to corrosion features. You can buy thee plates from a reputed and reliable vendor.

ASTM A516 Gr 60 Carbon Steel (NACE + HIC) Plate Specification :

Width: 1000mm-4500mm
Thickness: 5mm-150mm
Length: 3000mm-18000mm
Supply Condition:As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested : -52° C
Tempering: Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F.
Applications : Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service.
Process of Manufacturing : Hot-Rolled (HR)

ASTM A516 GR. 60 NACE Plate, A516 GR. 60 HIC Tested Plate Equivalent Standard:

British Standard	European Norm	ASTM/ASME	DIN
BS1501-161-430A	EN10028 P265GH	A/SA516 - Grade 60	DIN 17155 HII

ASTM A516 GR. 60 NACE Plate, A516 GR. 60 HIC Tested Plate Chemical Composition:

C	Si	Mn	P	S	Al	Cr	Cu	Ni	Mo	Nb	Ti	V	C.E.
0.20	0.4	0.95/1.50	0.010	0.002	0.02	0.3	0.3	0.3	0.08	0.01	0.03	0.02	0.420(max)

ASTM A516 GR. 60 NACE Plate, A516 GR. 60 HIC Tested Plate Mechanical Properties:

Tensile strength (ksi)	Yield strength (ksi)	Elongation min, % 200 mm (8 in)	Elongation min, % 50 mm (2 in)
415-550 (60-80)	250 (32)	21	25
