ASTM A516 GR. 70 NACE Plate, A516 GR. 70 HIC Tested

NACE HIC Tested A516 Grade 70 Boiler Plate Stockists, A516 Gr 70 HIC Resistant Steel Plate Supplier in Chennai, Suppliers of ASTM A516 Grade 70 NACE Carbon Steel Plates in Vadodara, ASME SA516 GR. 70 HIC Pressure Vessels Plate STOCKIST and SUPPLIERS in Maharashtra , Chhattisgarh , Kerala , Telangana , Gujarat ,Rajasthan , Madhya Pradesh , Uttar Pradesh , Tamil Nadu ,Kolkata,Karnataka India .We Also Export International China,Canada,Mexico,Japan,Germany,Italy,Brazil,Dubai,Saudi etc.

If you are also in the search of best quality of ASTM A516 GR. 70 (NACE + HIC) Plate then you have landed on the right place. These plates are used for a long time as they have a long life due to their best and advance manufacturing techniques. These plates are best and ideal for temperature rise work, high pressure and tank fabrication work where accurate & excellent toughness is required for better results. These ASTM A516 GR. 70 (NACE + HIC) Plate are manufactured in accordance with the national and international standards so that they can be accepted worldwide. Due to this, we supply our products to all the leading industries and customers who are satisfied with our production and quality.

All things considered, on the off chance that we discuss the particular for these plates they are made as per both national and global standard and detail that incorporates ASTM A516 GR.70 (NACE + HIC) Plate review. The thickness of these plates fluctuates somewhere around 5mm to 150mm while its width shifts from 1500mm to 2500mm or more according to the prerequisite and request of clients. These plates are regularly standardized from 1-1/2 frame and length fluctuates from 6000mm to 12000mm. These plates are accessible in various structures and shapes that incorporate standards, cleaned plates, shim plates, chilly moved plates, hot moved plates and weight vessel plates. The plates are accessible with reflect, emblazoned and hairline surface.

Have you at any point seen how these plates manage their quality and strength for quite a while? If not, at that point take note of that these plates run over different tests and assessments that assistance the producer to check the nature of plates. These tests are smoothing test, hardness test, smaller scale and large-scale test, IBR test, process test, ultrasonic test and then some. With it, producers offer different authentications like plant test declaration, hardness test testament and outsider examination report.

The most vital thing that issues the most to a client is items bundling. ASTM A516 GR. 70 (NACE + HIC) Plate are produced by driving makers; along these lines, they keep a legitimate mind the bundling procedure. To keep these plates from harms of rusting they pack these plates in best nature of wooden cases or boxes with the goal that they won't get rust or get harmed at the season of transportation and until its last phase of generation. Moreover, at the time bundling, finish stamping of the item is portrayed over the crate that incorporates the item name, size, length, and particular.

ASTM A516 GR. 70 NACE Plate, A516 GR. 70 HIC Tested Plate Equivalent Standard:

Width: 1000mm-4500mm
Thickness: 5mm-150mm
Length: 3000mm-18000mm
Supply Condition: As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested: -52° C
Tempering: Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F.
Applications: used in both pressure vessels and industrial boilers.
Process of Manufacturing: Hot-Rolled (HR)

ASTM A516 GR. 70 NACE Plate, A516 GR. 70 HIC Tested Plate Equivalent Standard:

British Standard	European Norm	ASTM/ASME	DIN
BS1501-224-490A/B	EN10028 P355GH	A/SA516 - Grade 70	-

ASTM A516 GR. 70 NACE Plate, A516 GR. 70 HIC Tested Plate Chemical Composition:

C

Si

Mn

P

S

Al

Cr

Cu

Ni

Mo

Nb

Ti

V

C.E.

0.10/ 0.22

0.6

1/ 1.5

0.010

0.002

0.02

0.3

0.3

0.3

0.08

0.01

0.03

0.02

0.420 (max)

ASTM A516 GR. 70 NACE Plate, A516 GR. 70 HIC Tested Plate Mechanical Properties:

Tensile strength MPa (ksi)	Yield strength MPa (ksi)	Elongation min, % 200 mm (8 in)	Elongation min, % 50 mm (2 in)
490-260 (70-90)	265 (38)	17	21
